220632 HALANSM Bevel Nozzle for Hypertherm HPR400A Plasma Torch Consumables (400A)

The HALANSM® 220632 Bevel Nozzle is a critical precision component designed for fabricators utilizing Hypertherm HPR400A plasma systems for high-definition bevel cutting operations . As the final point of contact for the plasma arc and swirling gas, this nozzle plays a vital role in focusing the plasma plume to achieve clean, dross-free bevel cuts required for precision welding preparation.

Engineered for Superior Bevel Cut Quality

Bevel cutting demands precise control over gas flow dynamics and arc constriction to penetrate thick materials at specific angles. The HALANSM 220632 nozzle features a specialized internal geometry that optimizes the vortex gas flow, ensuring the plasma arc remains stable and focused even when the torch is tilted. This results in superior cut edge quality with minimal dross adherence on mild steel profiles.

Key Features:

• Optimized Orifice: Precision-drilled orifice designed to maintain optimal standoff distance and arc voltage during high-current bevel operations.

• Extended Service Life: The high-purity CuCrZr alloy composition offers exceptional resistance to thermal erosion and mechanical wear, significantly outlasting standard OEM alternatives in demanding production environments.

• Leak-Free Seal: Equipped with dual high-temperature O-rings for a secure, leak-proof fit within the retaining cap, preventing coolant and gas leaks during operation.

• Systematic Replacement: To maintain peak cutting performance and prevent torch damage, Hypertherm recommends replacing the nozzle as part of a complete matched consumable set.

Complete 400A Bevel Consumable Stack Reference:

For optimal bevel cut quality and torch longevity, the HALANSM 220632 nozzle should be installed alongside the following compatible components:

• 400A Bevel Set: Electrode (220629), Swirl Ring (220631), Nozzle Assembly (220632), Shield (220636), Retaining Cap (220635), Shield Cap (220637) .

NOTE: The HALANSM 220632 is an aftermarket compatible replacement specifically designed for the 400A bevel cutting system. It is compatible with both the HPR400XD and HPR800XD series torches . Always ensure proper torch alignment when installing bevel consumables.
