HALANSM® Complete Plasma Cutting Consumables Kit for Hypertherm HyPro2000 Upgrade Torch for HT2000 — 50A / 130A / 200A, Air / Oxygen / Nitrogen

Full Component Breakdown by Amperage & Gas (per Hypertherm official matrix ):

HALANSM® Complete Plasma Cutting Consumables Kit — HyPro2000 Upgrade Torch for HT2000 (50A / 130A / 200A)

The HALANSM® HyPro2000 for HT2000 Full Consumables Kit is the definitive all-in-one replacement bundle for Hypertherm's HyPro2000 upgrade torch mounted on the HT2000 platform. Rather than sourcing individual consumables piecemeal — and risking the compatibility errors that cause double-arcing and premature wear — this kit bundles every component specified in Hypertherm's official HyPro2000 for HT2000 consumables matrix across the full 50A / 130A / 200A amperage range and Air / Oxygen / Nitrogen gas processes .

Why a full-range kit beats piecemeal ordering

Hypertherm themselves sell these as separate pre-configured kits: 228772 (O₂, 50A), 228773 (Air, 50A), 228770 (O₂, 130A), and 228771 (Air, 130A) . But fabrication shops rarely cut at just one amperage or one gas. The HALANSM bundle consolidates all of these into a single SKU — so when your production shifts from 50A air cutting of thin stainless to 200A oxygen cutting of thick mild steel plate, you have the right stack on the shelf, ready to go. No emergency orders, no downtime, no compatibility guesswork.

Key Features

• Complete 50A / 130A / 200A Coverage: Every electrode, nozzle, swirl ring, and shield specified in the official matrix is included . At 50A you get 220528 electrodes with 220890 (air) or 220891 (O₂) nozzles and 220532 shields; at 130A you get 220487 electrodes with 220892 (air) or 220893 (O₂) nozzles, paired with 220536 or 220491 shields; at 200A you get 220937 electrodes with 420044 (air) or 220831 (O₂) nozzles, paired with 420045 or 220832 shields. Every amperage, fully covered.

• Air / Oxygen / Nitrogen Ready: The kit includes gas-specific shields and nozzles so you can switch processes without compromise:

1. Air (mild steel / stainless / aluminum): 220532 (50A), 220536 (130A), 420045 (200A) shields; 220890 (50A), 220892 (130A), 420044 (200A) nozzles

2. Oxygen (mild steel): 220532 (50A), 220491 (130A), 220832 (200A) shields; 220891 (50A), 220893 (130A), 220831 (200A) nozzles

3. Nitrogen (stainless / aluminum, 200A only): 420045 shield + 420044 nozzle + 220529 swirl ring + 020415 electrode

• Universal Caps & Water Tube: The 220935 inner retaining cap (without tab) and 220936 outer shield cap (with IHS tab) are universal across all amperages and gases , as is the 220521 water tube . These are included in the quantity needed for a complete backup inventory.

• SilverPlus Option at 200A O₂: For maximum electrode life at 200A oxygen, the kit includes the option to add Hypertherm's SilverPlus electrode 220925 — which delivers up to 2× the life of standard copper electrodes . The standard 220937 copper electrode is included by default; 220925 SilverPlus can be substituted on request.

• OEM-Exact Dimensions: Every HALANSM component is manufactured to Hypertherm's published tolerances, ensuring perfect stack alignment. Proper alignment is critical — Hypertherm's maintenance documentation specifies that a non-round shield bore or worn swirl ring directly causes double-arcing and accelerated electrode/nozzle failure . The HALANSM kit eliminates that risk.

Complete Stack Reference (all amperages & gases)

50A Oxygen (Mild Steel)

220532 shield · 220936 outer cap · 220891 nozzle · 220529 swirl ring · 220528 electrode · 220521 water tube · 220935 inner cap (without tab)

50A Air (Mild Steel / Stainless / Aluminum)

220532 shield · 220936 outer cap · 220890 nozzle · 220529 swirl ring · 220528 electrode · 220521 water tube · 220935 inner cap (without tab)

130A Oxygen (Mild Steel)

220491 shield · 220936 outer cap · 220893 nozzle · 220488 swirl ring · 220487 electrode · 420185 SilverPlus · 220521 water tube · 220935 inner cap (without tab)

130A Air (Mild Steel / Stainless / Aluminum)

220536 shield · 220936 outer cap · 220892 nozzle · 220488 swirl ring · 220487 electrode · 220521 water tube · 220935 inner cap (without tab)

200A Oxygen (Mild Steel)

220832 shield · 220936 outer cap · 220831 nozzle · 220834 swirl ring · 220937 electrode · 220521 water tube · 220935 inner cap (without tab)

(SilverPlus option: 220925 electrode)

200A Air (Mild Steel / Stainless / Aluminum)

420045 shield · 220936 outer cap · 420044 nozzle · 220488 swirl ring · 220937 electrode · 220521 water tube · 220935 inner cap (without tab)

200A Nitrogen (Stainless / Aluminum)

420045 shield · 220936 outer cap · 420044 nozzle · 220529 swirl ring · 020415 electrode · 220521 water tube · 220935 inner cap (without tab)

NOTE: This HALANSM® consumables kit is engineered for the HyPro2000 upgrade torch for HT2000, covering 50A, 130A, and 200A across Air, Oxygen, and Nitrogen processes — built to Hypertherm's official HyPro2000 for HT2000 consumables matrix . The same components are also compatible with HyPro2000 retrofit for MAX200 and native MAXPRO200 machine torches . Universal components: inner cap 220935 (without tab), outer cap 220936 (with IHS tab), and water tube 220521 — these fit all amperages and gases . For 200A Oxygen, the optional 220925 SilverPlus electrode delivers 2× the life of the standard 220937 copper electrode . Always inspect shields for a non-round bore and replace swirl rings when gas holes are clogged or damaged — Hypertherm's maintenance guide identifies these as primary causes of double-arcing and accelerated consumable failure . HALANSM® is an independent aftermarket manufacturer; these parts are compatible replacements for Hypertherm® systems.

Real Shot: Images above show the actual HALANSM torch ceramic head, Euro connector pins, cable coil, consumable-installed view and length comparison you will receive.

Download the complete product brochure：
