This HALANSM® Extended Plasma Nozzle and Electrode set is specifically designed for the Hypertherm Powermax 45 / 45A systems. The elongated nozzle geometry allows operators to cut in deep channels, narrow corners, or obstructed areas where standard consumables cannot reach. Combined with a high-quality silver-series electrode, this set ensures consistent cut quality, faster piercing, and reduced dross in challenging fabrication environments.
Extended Nozzle & Electrode Set
HALANSM®
Enhanced Reach and Precision for Complex Cutting Applications
The HALANSM® Extended Plasma Nozzle (left) and Electrode (right) set is the ultimate solution for operators facing spatial constraints or requiring enhanced visibility during plasma cutting. Unlike standard consumables, the extended nozzle provides up to 1.5 inches of additional standoff distance, allowing the torch to access inside box sections, along narrow flanges, or deep within weld preparations.
Key Features & Benefits
Improved Access & Visibility: The elongated nozzle design provides the necessary standoff for cutting in recessed areas or tight corners where a standard 0.6-inch nozzle would collide with the workpiece.
Ultra-Stable Arc Performance: Precision-machined internal bores ensure laminar gas flow, resulting in a stable, focused arc column that minimizes edge dross and ensures clean, precise cuts.
Extended Service Life: Both components are manufactured from high-conductivity copper alloys. The electrode features advanced Silver-Plus® technology to resist premature erosion and maintain cut quality throughout its lifecycle.
HALANSM Quality Assurance: Every set undergoes rigorous quality control to meet OEM standards, offering professional-grade performance at a highly competitive value.
Installation & Compatibility Guide
Proper Stack Assembly: For optimal results, assemble in this order: Electrode (220438) -> Swirl Ring (220816) -> Extended Nozzle (220479) -> Shield Cap (220674).
Fine Cut Technology: If using this set for ultra-fine drag cutting on thin gauge materials, ensure the nozzle orifice is clean and the torch is held at the manufacturer's recommended angle to prevent double arcing.
System Compatibility: These consumables are exclusively designed for the Powermax 45 / 45A "T45" series hand torches (2208xx family). They are not compatible with the Powermax 65/85/105 systems or the HSD130 45A system.
Real Shot: Images 1–11 above show the actual HALANSM torch ceramic head, Euro connector pins, cable coil, consumable-installed view and length comparison you will receive.
