HALANSM® Kjellberg Z102 Swirl Ring .11.835.221.154

HALANSM®

SILVER CUTTING

HLN-Z111A / .11.835.421.303

HALANSM® Gas Guide Z102 Swirl Ring .11.835.221.154 for Kjellberg Plasma Cutting Torch Consumables Replacement

HALANSM® HLN-Z102 is an aftermarket plasma swirl ring (gas guide) with copper alloy, built for Kjellberg HiFocus 130i / 160i and PerCut 160 / 170 torches to deliver stable vortex gas flow and clean cuts in the 20-130A range.

Need a Z102 gas guide for HiFocus 130i or 160i? HALANSM® HLN-Z102 replaces Z102 / .11.835.221.154 as an aftermarket swirl ring that maintains gas swirl, protects the electrode and nozzle, and supports O2, air, N2 and ArH2 processes.

Product Overview

The HLN-Z102 gas guide installs between the electrode and nozzle in the Kjellberg HiFocus / PerCut torch wear stack. Its annular body with side slots and sealing ring generates controlled swirl in the plasma gas, narrowing and stabilizing the arc. Copper construction handles sustained torch-head heat while preserving bore geometry.

Key Advantages

Stable Vortex Flow

Machined side slots and central bore create uniform gas rotation for narrower kerf and less dross.

Copper Heat Resistance

Copper alloy body dissipates heat and resists deformation across the 20-130A duty range.

Sealing Ring Included

Integrated sealing ring (based on product image) supports gas retention; confirm material and temp range with your torch model.

Aftermarket Batch Inspection

Each lot checked for bore, slot pattern and seating tolerance. Store dry and dust-free before use.

Specifications

Compatible Equipment / Application

HALANSM® HLN-Z102 fits Kjellberg HiFocus 130i and 160i plasma systems with PerCut 160 / 170 torches, for the 20-130A current range. It is an aftermarket replacement compatible with Z102 / .11.835.221.154, not original Kjellberg. Provide your torch model and original part number for fitment check.

Current Range Selection

Do not install a 280-400A swirl ring (G121) into a 20-130A HiFocus 130i/160i stack. Mismatched seat profile and current rating disrupt vortex flow and accelerate electrode and nozzle wear.

Installation and Handling

· Power off the plasma source and fully release gas pressure.

· Remove the worn shield, old swirl ring, nozzle and electrode.

· Clean the torch seat, threads and gas passages; inspect O-rings.

· Install the electrode, then seat the Z102 gas guide with slots oriented to the torch reference.

· Add the nozzle and shield; hand-tighten only, no forced press-fit.

· Run a low-current test cut to verify arc stability and gas swirl.

Frequently Asked Questions

What Kjellberg torches fit HALANSM® HLN-Z102?

HLN-Z102 fits HiFocus 130i and 160i systems with PerCut 160 / 170 torches, 20-130A. It is an aftermarket Z102 / .11.835.221.154 replacement. Send your torch model for final fitment check.

Is Z102 an original Kjellberg part?

No. HLN-Z102 is an aftermarket consumable compatible with Z102 / .11.835.221.154. It is not original Kjellberg equipment and is not factory authorized.

What material is the Z102 swirl ring?

HLN-Z102 uses copper alloy with an integrated sealing ring. The ring material and temperature range should be confirmed against your specific torch model.

Can Z102 be used for O2 and air plasma?

Yes. Z102 supports O2, air, N2 and ArH2. Match the electrode and nozzle to the selected gas; O2 and air nozzle bores are not interchangeable.

Why does cut quality drop after replacing the swirl ring?

Worn or wrong swirl slots break gas vortex. Common causes: mismatched 20-130A versus 280-400A rings, clogged slots, dirty seat or over-tightened cap. Clean the seat, confirm Z102 and test at low current.

How should I store spare Z102 swirl rings?

Keep in original packaging, dry and dust-free. Avoid oil, moisture and stacked metal that can deform the bore or sealing ring groove.

Related Products

From the official HALANSM® Kjellberg consumables catalog:

• HLN-Z4020 — 2.0mm swirl gas cap for 50-80A Kjellberg HiFocus PerCut.


• HLN-Z4022 — 2.2mm swirl gas cap for 80-100A Kjellberg HiFocus PerCut.

• HLN-Z4025 — 2.5mm swirl gas cap for 100-160A Kjellberg HiFocus PerCut.

• HLN-Z4030 - 3.0 mm swirl gas cap for the 160-200 A range.

• HLN-G4350 — Shield G4350 .11.848.401.1550 for Kjellberg HiFocus 280-360A (not PB-S interchangeable).

• HLN-G501 — Protection Cap for HiFocus 130i/161i/280i, OEM G501 (.11.848.201.081), 20–200A.

• HLN-G101 — Swirl Ring / Gas Guide for HiFocus 130i/160i/280i, OEM G101 (.11.848.221.145), up to 130A.

• HLN-G2012Y — CoolFlow Nozzle for HiFocus 130i/161i/280i, OEM G2012Y (.11.848.221.412), 130A O₂.

• HLN-G4020 — Swirl Gas Cap / Shield for HiFocus 130i/161i/280i, OEM G4020 (.11.848.201.1520), 60A.

• HLN-G901Y — Cooling Tube for HiFocus 130i/160i/280i, OEM G901Y (.11.848.201.142), 20–200A.

• HLN-G002Y — Silver Electrode for HiFocus & PerCut, OEM G002Y (.11.848.221.300), 20–200A O₂.

• HLN-G121 — Gas guide swirl ring for HiFocus 280i/360i/440i, 280-400A (G121 / .11.848.421.145).

• HLN-G931Y — Cooling tube for HiFocus 280i/360i/440i, 280-400A (G931Y / .11.848.401.142).

• HLN-G032Y — Silver electrode for HiFocus 360i/440i, 280A O2 (G032Y / .11.848.421.310).

• HLN-G092Y — Electrode G092Y .11.848.401.310 for Kjellberg HiFocus and PerCut high-current use.

• HLN-S002Y — SilverLine electrode for Kjellberg HiFocus O2 cutting.

• HLN-V101 — Gas guide V101 .12.40860 for PA-S series torches (not PB-S interchangeable).

• HLN-V4345 — Swirl gas cap V4345 .11.833.101.157, 4.5 mm bore for FineFocus / PB-S dry cutting.

• HLN-V4350 — Swirl gas cap V4350 (.11.833.101.158) 5.0 mm for FineFocus / PB-S80 higher current.

• HLN-T012Y — SilverLine electrode T012Y (.11.844.921.300) for FineFocus 800/900 PB-S80 O2/air.

• HLN-G101C — Ceramic swirl ring .11.848.221.145C for 35-200A Kjellberg gas guide.

• HLN-G4020 — Swirl gas cap G4020 .11.848.201.1520 for Kjellberg HiFocus / PerCut 60A stacks.

All models above are real HALANSM® products. Match the size and rating to your specific head before ordering.

HALANSM®. All rights reserved.  |  ISO 9001:2015 Certified Manufacturing
