The HALANSM® 220553 is the 50A mild steel swirl ring for the Hypertherm HPR plasma torch family — HPR130, HPR260, HPR130XD, HPR260XD, HPR400XD, HPR800XD, HD3070, HD4070. Volcanic ash ceramic body, clockwise gas-flow orientation, precision-machined tangential inlet ports that impart a high-velocity vortex to the plasma gas . This vortex is what constricts and stabilizes the arc, creates a cooler boundary layer along the nozzle wall to prevent double-arcing, and centers the arc for square, symmetrical cuts . In the HPR 50A stack it pairs with 220552 electrode + 220554 nozzle + 220754 retaining cap + 220555 shield + 220747 shield cap + 220340 water tube . HALANSM 220553 is OEM-profile matched to Hypertherm 220553 geometry, lower cost-per-piece than OEM. Compatible aftermarket replacement, not Hypertherm OEM.
220553
HALANSM®
HLN-220553
Swirl Ring 220553 / 50A Mild Steel Swirl Ring for HPR Series – HALANSM®
220553 is Hypertherm's 50A mild steel swirl ring for the HPR plasma torch family. Volcanic ash ceramic body, clockwise orientation, precision-machined tangential inlet ports that impart a high-velocity vortex to the plasma gas . This vortex is the unseen architect of cut quality: it constricts and stabilizes the arc, creates a cooler gas boundary layer inside the nozzle to prevent double-arcing, centers the arc for square cut edges, and promotes even thermal distribution for
uniform electrode/nozzle wear .
220553 in the HPR 50A Mild Steel Stack
Pos | Part | Ref |
|---|---|---|
Electrode | 220552 (50A) | 220552 |
Swirl Ring | 220553 (50A MS, CW) | 220553 |
Nozzle | 220554 (50A) | 220554 |
Retaining Cap | 220754 (30–50A) | 220754 |
Shield | 220555 (50A MS) | 220555 |
Shield Cap | 220747 (30–130A HPRXD) / 220173 (30–130A HPR130/260-class) | 220747 / 220173 |
Water Tube | 220340 (45–260A) | 220340 |
Key Points (buyer-facing)
50A MS swirl, one part number crosses ALL HPR machines: 220553 fits HPR130, HPR260, HPR130XD, HPR260XD, HPR400XD, HPR800XD, HD3070, HD4070 identically . The only differences in the 50A stack are the shield cap on top (220747 on HPRXD-class, 220173 on HPR130/260-class) and water tube (220340) — the swirl ring itself is universal.
Clockwise gas orientation: 220553 is the clockwise-flow swirl ring for the 50A mild steel application . Installing it backwards (counterclockwise orientation) will not produce the correct vortex — always match the "CW" orientation marking.
NOT a generic ceramic ring: The volcanic ash ceramic body + high-temp O-rings are precision-CNC-machined to exact port angle, size, and surface finish . Generic rings with wrong port geometry will cause arc wander, double-arcing, and premature nozzle failure .
Change as a set: Per Hypertherm's guidance, HPR consumables interact synergistically — replace electrode + swirl + nozzle + retaining cap + shield + shield cap together for peak cut quality and life .
NOTE: 220553 = 50A MS swirl ring, clockwise. Same part number fits HPR130/HPR260/HPR130XD/HPR260XD/HPR400XD/HPR800XD/HD3070/HD4070. The 50A stack differs only in shield cap (220747 HPRXD-class / 220173 HPR130/260-class) and water tube (220340). HALANSM 220553 is an aftermarket compatible replacement, not Hypertherm OEM.
