The HALANSM 220991 is a high-performance shield cap specifically designed for the Max Removal Gouging process on the Hypertherm Powermax 105/105A system. Crafted from premium copper alloys, this consumable provides superior arc stability and extended service life when working with thick metals, ensuring efficient material removal and high-quality results.
220991
HALANSM
HLN-220991
HALANSM 220991 Shield Cap - Max Removal Gouging Solution
The shield cap is the outermost protective component in the plasma consumable stack. It protects the nozzle and swirl ring from spatter and ensures proper gas flow around the cutting edge.
Features of the HALANSM 220991:
Optimized for Gouging: Specifically engineered for the "Max Removal Gouging" application on the Powermax 105A system. It handles high currents (up to 105A) required for aggressive material removal.
Enhanced Durability: Made from high-conductivity copper material that withstands extreme thermal stress and resists wear better than standard grades.
Perfect Fit: Designed with precision tolerances to fit seamlessly with the 220797 nozzle and 220798 deflector, ensuring a stable plasma arc every time.
Compatible Powermax Consumable Stack:
For optimal cutting performance, it is recommended to replace the electrode alongside other wear parts.
Type
Amp
Shield/Deflector
Retaining Cap
Nozzle
Electrode
Swirl Ring
Hand
45
220818
220854
220941
220842 or 220777
220857
65
220819
85
220816
105
220992
220990
220994
Machine
45
220817 or 220955
220854 or 220953
220941
220842 or 220777
220857
65
220819
85
220816
105
220993 or 220955
220990
220994
Finecut
45
220931
220948
220854 or 220953
220930
220842
220947
Gouging
45-105
220798
220854
220797 220991
220842
220994
| No | Ref No | Description |
| 1 | 220992 | Shield for Plasma cutting torch consumables Handheld 105A |
| 220993 | Shield for Plasma cutting torch consumables Mechanized105A | |
| 220818 | Shield for Plasma cutting torch consumables Handheld 45A/65A/85A | |
| 220817 | Shield for Plasma cutting torch consumables Mechanized 45A/65A/85A | |
| 220955 | Shield for Plasma cutting torch consumables Mechanized 45A/65A | |
| 220948 | Shield for Plasma cutting torch consumablesHandheld 45A/65A/85A | |
| 2 | 220854 | Retaining Cap for Plasma cutting torch consumables5A/65A/85A |
| 3 | 220941 | Nozzle for Plasma cutting torch consumablesHandheld 45A |
| 220819 | Nozzle for Plasma cutting torch consumablesHandheld 65A | |
| 220930 | Nozzle for Plasma cutting torch consumables | |
| 220816 | Nozzle for Plasma cutting torch consumables 85A | |
| 220990 | Shield for Plasma cutting torch consumables 105A | |
| 4 | 220842 | Electrode for Plasma cutting torch consunables 45A/65A/85A/105A |
Need help identifying other Hypertherm XPR consumables? Feel free to contact our support team for assistance.
