Nozzle 0558006025 For ESAB PT36 Plasma Cutting Torch Consumables (2.5mm 300A)
The nozzle is the part that constricts and directs the plasma arc. 0558006025 is the 2.5mm / 300A nozzle in the ESAB PT36 stack—positioned right after the swirl ring to compress the arc column and deliver a focused, high-velocity gas jet for medium-thickness plate work.
Key Features
Precision 2.5mm Orifice: Bore finished to ESAB PT36 geometry so the plasma jet stays consistent; critical for edge squareness and dross control at 300A.
High Thermal Conductivity: Copper alloy body dissipates heat from the arc zone, keeping shape stable and life predictable under sustained 300A runs.
O-Ring Seal Land: Smooth seat surface mates with the shield cup to prevent gas bypass and cooling-water weep at high pressure.
Drop-In Fit: Threads, length and outer profile follow the ESAB 0558006025 envelope—no filing, no shimming.
Compatible 300A PT36 Stack Reference（同系列口径）
Pos | Component | Ref # |
|---|
Electrode | 0558012000 | 0558012000 |
Swirl / Baffle | PT36 swirl family | 0558002533 / 21944 |
Nozzle | 0558006025 | 0558006025 |
Shield Cap | 0558006166 (6.6mm, 290-450A) / next size | 0558006166 |
Retaining Cap | PT36 retaining | 37082 / 37081 |
Torch Body | 0558003804 | 0558003804 |
Real Shot: Actual product photos shown above represent the exact item you will receive.
