Nozzle 0558006014 For ESAB PT36 Plasma Cutting Torch Consumables (1.4mm 100A)
The nozzle is the part that constricts and directs the plasma arc. 0558006014 is the 1.4mm / 100A nozzle in the ESAB PT36 stack—positioned right after the swirl ring to compress the arc column and deliver a focused, high-velocity gas jet for precision cutting on thin materials.
Key Features
Precision 1.4mm Orifice: Bore finished to exacting standards to maintain a consistent plasma jet, ensuring clean edges and minimal dross formation during 100A cutting operations.
Superior Thermal Management: Constructed from premium copper alloys that offer exceptional thermal conductivity to handle the intense heat of the plasma arc, reducing warping and extending consumable life.
Leak-Proof Seal: Features precision-machined O-ring grooves that provide a secure, leak-proof seal against the shield cup, maintaining proper gas flow and torch integrity.
Direct OEM Interchangeability: Designed to match ESAB 0558006014 specifications exactly. Drop-in replacement with no modifications required for easy installation.
Compatible 100A PT36 Stack Reference（同系列口径）
Position | Component | Reference Number |
|---|
Electrode | 0558012000 | 0558012000 |
Swirl / Baffle | PT36 Swirl Ring Family | 0558002533 / 21944 |
Nozzle | 0558006014 | 0558006014 |
Shield Cap | 0558006166 (6.6mm) | 0558006166 |
Retaining Cap | PT36 Retaining Cap | 37082 / 37081 |
Torch Body | 0558003804 | 0558003804 |
Real Shot: Actual product photos shown above represent the exact item you will receive.
Need help identifying other Hypertherm XPR consumables? Feel free to contact our support team for assistance.
