Technical Specifications
Product Description
Catalogue
Part Type
MCSB Raised Laser Cutting Nozzle (internal step)
Outer Diameter
15 mm
Height
15 mm
Thread
M11
Tip Form
Raised cone with internal step
Layer Type
Single layer / Double layer
Material
High-purity copper, chrome plating optional
Bore Caliber
1.2 / 1.4 mm (full range 0.8 - 3.0 mm)
Application
Carbon-steel cutting on high-power fiber lasers
HALANSM®
SILVER CUTTING
HLN-MCSB-D15H15M11
HALANSM® MCSB Raised Nozzle with Internal Step, OD 15 mm x H 15 mm x M11
Aftermarket copper MCSB raised nozzle for Han's and compatible high-power fiber laser cutting heads
HALANSM® HLN-MCSB-D15H15M11 is an aftermarket MCSB raised nozzle sized OD 15 mm x H 15 mm x thread M11, built for Han's (DNE) and compatible high-power fiber laser cutting heads. Its raised tip with an internal step directs assist gas for stable carbon-steel cutting at higher power levels.
Product Overview
HLN-MCSB-D15H15M11 is a flat-based nozzle with a raised conical tip and an internal step (inner counterbore) that controls gas convergence at the orifice. It mounts at the front of the cutting head above the ceramic ring. The internal step and raised profile distinguish it from a standard straight-bore nozzle; confirm exact specs with us before ordering.
Key Advantages
Raised Tip with Internal Step
The raised cone plus internal counterbore concentrates assist gas, supporting stable kerf and slag control on carbon steel.
High-Purity Copper
Copper body with optional chrome plating for thermal conductivity, wear resistance and a smooth inner wall.
Single or Double Layer
Available in single and double layer for nitrogen or oxygen cutting. Confirm exact specs with us.
Batch Consistency
CNC-machined bores are inspected for concentricity, so reorder batches stay repeatable.
Specifications
Core parameters:
Part Type
MCSB Raised Laser Cutting Nozzle (internal step)
Outer Diameter
15 mm
Height
15 mm
Thread
M11
Tip Form
Raised cone with internal step
Material
High-purity copper, chrome plating optional
Layer Type
Single layer / Double layer
Bore Caliber
1.2 / 1.4 mm (full range 0.8 - 3.0 mm)
Application
Carbon-steel cutting on high-power fiber lasers
Compatible Equipment and Application
Compatible with aftermarket Han's (DNE) and other cutting heads using a D15 H15 M11 nozzle with raised-tip / internal-step form factor. Provide your head model and original part number for fitment check.
D15 M11 size family (reference):
OD 15 mm, H 15 mm, M11
MCSB raised nozzle (this page)
OD 15 mm, H 18 mm, M11
Empower / RayTools 3D head nozzles
OD 15 mm, H 19 mm, M11
Jiaqiang / Empower 3D nozzles
OD 15 mm, H 22 mm, M11
Bevel / five-axis nozzles
Selection Guide
Match outer diameter, height and thread first: this nozzle is D15 x H15 x M11 with a raised tip. Then choose bore caliber by material and gas: 0.8 - 1.5 mm for thin sheet with nitrogen, 2.0 - 3.0 mm for thicker carbon steel with oxygen. Confirm exact specs with us.
Installation and Handling
1. Power down the laser and release all assist-gas pressure.
2. Unscrew the worn nozzle from the ceramic ring or nozzle seat.
3. Clean the mounting seat and ceramic interface with a lint-free cloth.
4. Align the M11 thread by hand, then tighten only until snug.
5. Recalibrate the capacitive sensor, then run a low-power test cut on scrap.
6. Store spares in a dry, sealed container away from dust and moisture.
Frequently Asked Questions
What laser heads fit the HALANSM® HLN-MCSB-D15H15M11 MCSB raised nozzle?
It fits Han's (DNE) and compatible heads using a D15 H15 M11 nozzle with raised-tip and internal-step form. Provide your head model and original part number for fitment check.
Is the HLN-MCSB-D15H15M11 an original Han's or DNE nozzle?
No. It is an aftermarket replacement made to the D15 H15 M11 form factor. Han's and DNE are used only for fitment identification.
What does the internal step do?
The internal step controls gas convergence at the orifice, helping stabilize the cut on carbon steel. Exact performance depends on your setup.
How do I choose the bore caliber?
Use 0.8 - 1.5 mm for thin sheet with nitrogen and 2.0 - 3.0 mm for thicker carbon steel with oxygen. Confirm exact specs with us.
When should I replace the MCSB nozzle?
Replace it when the bore clogs with slag, the raised tip deforms, or cut quality drops. Timely replacement protects the ceramic ring.
Can I install the HLN-MCSB-D15H15M11 myself?
Yes. Power down, remove the old nozzle, clean the seat, hand-tighten the new nozzle, recalibrate the sensor, and test cut.
