HALANSM® D15 H19 M8 3D Nozzle

HALANSM®

SILVER CUTTING



HLN-JQ3D-M8-D15H19

HALANSM® D15 H19 M8 3D Laser Nozzle

Aftermarket copper 3D nozzle for Jiaqiang, Empower and RayTools-compatible tube cutting heads

HALANSM® HLN-JQ3D-M8-D15H19 is an aftermarket 3D laser cutting nozzle sized OD 15 mm x height 19 mm x thread M8, built for Jiaqiang (Empower) 3D cutting heads and compatible RayTools tube-cutting lasers to deliver stable assist-gas flow and clean cuts on pipes and shaped profiles.

Product Overview

The HLN-JQ3D-M8-D15H19 mounts at the front of a Jiaqiang / Empower 3D or tube-cutting laser head. Its conical tip and concentric bore direct assist gas to eject molten material as the head rotates and tilts around the workpiece. The M8 thread and knurled seat keep the nozzle seated through long production runs.

Key Advantages

High-Purity Copper Body

Machined from high-purity copper for strong thermal and electrical conductivity during high-speed 3D cutting.

Conical Tip, Collision Resistant

Streamlined cone profile reduces snagging on tube edges and resists impact during five-axis motion.

Single or Double Layer

Available in single layer for nitrogen cutting and double layer for oxygen work. Confirm exact specs with us.

Polished Bore, Smooth Flow

Smooth inner wall maintains laminar gas flow for clean edges and less spatter adhesion.

Specifications

Part Type	3D Laser Cutting Nozzle
Outer Diameter	15 mm
Height	19 mm
Mounting Thread	M8
Material	High-purity copper
Layer Type	Single layer / Double layer
Bore Caliber	1.0 / 1.5 / 2.0 / 2.5 / 3.0 mm
Application	Fiber laser 3D / tube cutting

Compatible Equipment and Application

Compatible with aftermarket Jiaqiang (Empower) 3D cutting heads and other tube-cutting heads using an M8 nozzle interface, including heads compatible with RayTools BM/BS 3D families. Provide your head model and original part number for fitment check.

M8 size family (do not substitute M9 / M11 threads):

OD 8 mm	D8 family, height 10 mm, thread M8, Ospri / tube-cutting heads
OD 10 mm	D10 family, height 19 mm, thread M8, PRIMA 3D heads
OD 12 mm	D12 family, height 10 mm, thread M8, precision 3D single-layer heads
OD 15 mm	D15 family, height 19 mm, thread M8, this model (Jiaqiang / Empower 3D)

Selection Guide

Use 1.0 - 1.5 mm for thin-wall tube with nitrogen, and 2.0 - 3.0 mm for thicker wall with oxygen. Confirm exact specs with us for your material and gas.

Choose single layer for nitrogen and fine-finish cutting; choose double layer for oxygen and heavy-duty cutting. Confirm exact specs with us.

Installation and Handling

1. Power down the laser and release all assist-gas pressure.

2. Unscrew the worn nozzle from the ceramic ring or nozzle seat.

3. Clean the mounting seat and ceramic interface with a lint-free cloth.

4. Align the M8 thread and hand-tighten the new nozzle; do not overtighten.

5. Recalibrate the capacitive sensor, then run a low-power test cut on scrap.

6. Store spares in a dry, sealed container away from dust and moisture.

Frequently Asked Questions

What laser heads fit the HALANSM® HLN-JQ3D-M8-D15H19 3D nozzle?

It fits Jiaqiang (Empower) 3D heads and compatible tube-cutting heads with an M8 nozzle interface. Provide your head model and original part number for exact fitment.

Is the HLN-JQ3D-M8-D15H19 an original Jiaqiang or RayTools part?

No. It is an aftermarket replacement made to the D15 H19 M8 form factor. Jiaqiang, Empower and RayTools are third-party trademarks used only for fitment identification.

What material is the HLN-JQ3D-M8-D15H19 made of?

High-purity copper with a polished bore. Layer type and surface finish vary by SKU; confirm exact specs with us.

How do I choose the right bore caliber?

Use 1.0 - 1.5 mm for thin-wall tube with nitrogen and 2.0 - 3.0 mm for thicker wall with oxygen. Confirm exact specs with us.

When should I replace the 3D nozzle?

Replace it when the bore clogs with slag, the tip deforms, or cut quality drops. Timely replacement protects the ceramic ring.

Can I install the HLN-JQ3D-M8-D15H19 myself?

Yes. Power down, remove the old nozzle, clean the seat, hand-tighten the new nozzle, recalibrate the sensor, and test cut.

Related Products

• HLN-OSPRI3D-M8-D8H10 — D8 H10 M8 3D Nozzle for Ospri OSPRI 305 and tube lasers.

• HLN-CR-D195M8 — 3D Ceramic Ring D19.5 x M8 for RayTools and OSPRI 3D cutting heads.

• HLN-CR-2832 — 28 x 32 Ceramic Ring for fiber laser cutting heads.

• HLN-CR-D41M11 — JQ-D41 Ceramic Ring for Empower BS12K laser cutting head.

• HLN-3DM9-D18H20 — D18 H20 M9 3D Nozzle for Gangchun and compatible tube-cutting heads.

• HLN-PRIMA3D-M8-H19S — D10 H19 M8 Single-Layer Nozzle for PRIMA 3D cutting heads.

• HLN-CL-27941 — 27.9 x 4.1 Protective Lens for RayTools BM110 and BT240 heads.





All models above are real HALANSM® products. Match the window size and power rating to your specific head before ordering.



---

HALANSM®. All rights reserved.  |  ISO 9001:2015 Certified Manufacturing
