HALANSM® D15 H18 M11 3D Bevel Laser Nozzle
Single and double layer copper 3D bevel nozzle for Empower and RayTools-compatible fiber laser cutting heads.
HALANSM® HLN-3DB-D15H18M11 is an aftermarket 3D bevel laser nozzle sized OD 15mm x H 18mm x thread M11, built for Empower (JQ) and RayTools-compatible 3D bevel and tube cutting heads to deliver stable assist-gas flow and clean bevel cuts.
Product Overview
The 3D Bevel Laser Nozzle is the front-end consumable of a 3D fiber laser cutting head. Its conical bevel tip and precision bore direct the assist gas to evacuate molten slag during angled and multi-axis cuts.
A stable gas channel keeps the kerf clean on bevel, pipe, and 3D profile work. Replacing a worn or off-center nozzle restores edge quality and protects the ceramic body and protective lens.
Key Advantages
· Concentric Bore Precision concentric bore for stable gas flow and consistent kerf quality.
· Copper Construction High-purity copper body for efficient heat dissipation and thermal conductivity.
· Single or Double Layer Single and double layer options to match the assist gas and material thickness.
· 3D Bevel Geometry Beveled conical tip designed for angled cutting and slag evacuation.
3D bevel cutting, pipe/tube cutting, multi-axis profile cutting
Compatible Equipment and Application
This D15-H18-M11 family is intended for Empower (JQ) 3D bevel cutting heads and tube cutting machines, and for RayTools-compatible 3D heads that use the same M11 interface.
· Empower JQ Empower / JQ () 3D bevel and tube cutting heads — primary fitment.
· RayTools RayTools 3D families — confirm thread before ordering; RayTools standard 3D is D15-H19-M8, this part is D15-H18-M11.
· Other Brands Penta, BOCI, OSPRI and other M11-interface 3D heads — verify head model and original part number.
Provide your head model and original part number for fitment check. This is an aftermarket replacement; no OEM authorization is claimed.
Nozzle Selection by Size Family
Do not mix thread standards across the D15 family. Match both height and thread to your cutting head before ordering.
· D15 H19 M8 D15 H19 M8 — RayTools BM/BS 3D families (different thread, not interchangeable).
· Other D-Sizes D11.5 / D10.5 variants — fine-style and high-power heads, different OD.
Use smaller calibers with nitrogen or air for thin sheet, larger calibers with oxygen for thicker material. Confirm exact specs with us for your process chart.
Installation and Handling
1. Power off the laser and release all assist-gas pressure.
2. Unscrew the worn nozzle and inspect the ceramic seat and threads.
3. Clean the mounting face with lint-free optical paper; check the O-ring.
4. Thread the new 3D Bevel Laser Nozzle by hand until seated, then snug lightly — never over-tighten.
5. Reconfirm the focus offset and run a low-power test cut before production.
Frequently Asked Questions
What laser heads fit the HLN-3DB-D15H18M11 3D bevel nozzle?
It fits Empower (JQ) D15-H18-M11 3D bevel and tube cutting heads, and compatible RayTools-style heads. Provide your head model for a fitment check.
Is the HLN-3DB-D15H18M11 an original Empower or RayTools part?
No. It is an aftermarket replacement made to the D15 H18 M11 specification. Empower, JQ and RayTools are third-party trademarks used only for compatibility reference.
What is the difference between single and double layer?
Single layer is commonly paired with nitrogen or air; double layer is typically used with oxygen. Selection depends on material, thickness, and your cutting program.
What bore caliber should I choose?
Common calibers run from 1.0 to 3.0mm. Smaller bores suit thin sheet with nitrogen, larger bores suit thicker plate with oxygen. Follow your cutting chart or confirm with us.
How do I avoid mixing up M8 and M11 nozzles?
The D15 family comes in H19 M8 (RayTools standard 3D) and H18 M11 (Empower/JQ). Always check the thread marking on the nozzle base before installation.
When should the nozzle be replaced?
Replace it when the bore is distorted, slag blocks the channel, the tip is damaged from collision, or cut quality becomes inconsistent.
